Pipe cross comes into equal cross and reducing cross,and the raw materials of which include a wide range, like carbon steel, alloy steel, stainless steel, low temperature steel, and high performance steel, etc. Our pipe crosses feature high strength, good toughness and resistance to corrosion, and they are widely used in many industries, such as petroleum, power generation, natural gas, chemical, shipbuilding, paper making etc.
Pipe Cross Types
Equal Cross
Ang pantay na pipe krus ay isang uri ng pipe krus, tulad ng isang pantay-pantay katangan, ang pantay-pantay na mga krus ay nangangahulugang ang lahat ng 4 mga dulo ng krus ay nasa parehong lapad. Ang pipe krus, gaya ng isang kalsada krus, ay ang magkasanib na ng 4 pipa. Tumatanggap ang presyon mula sa 4 pipe, pag-isahin joint sa pagitan ng pipe at krus ay dapat na napaka-strong.
Pagbawas krus
Ang Pagbawas Cross Pipe umaangkop tinatawag din bilang patas pipe krus, ito ay ang pipe krus kung saan ay may apat na dulo ng sangay ay hindi sa parehong diameters.
Sa labas Diameter : Seamless Cross Fitting ( 1/2″～24″), ERW / Welded / Fabricated Cross Fitting (1/2″～48″)
uri: Walang hirap, Welded, Katumbas Cross, Pagbawas Cross
Wall Kapal: 3mm – 40mm / SCH5, SCH10, SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Value Added Services : Hot Dipped Galvanizing, Epoxy & FBE Coating, Electro Polish, Sand Blasting, Threading, Paghihinang
Produksyon ng Grades: hindi kinakalawang na asero, haluang metal Steel, Duplex, Nickel Alloys, Mababang temperatura Steel, Carbon Steel, Couple Nickel
manufacturing Standards
ASME: ANSI B16.9, ANSI B16.28, MSS-SP-43
DIN: DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN: EN10253-1, EN10253-2
ASTM A403 – ASME SA403 – Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings
ASME B16.9 – Factory-Made Wrought Fittings Butt welding
ASME B16.25 – Butt welding Ends ASME B16.28 – Wrought Steel Short Radius Elbows and Butt welding Returns
MSS SP-43 – Wrought and Fabricated Butt-Welding Fittings for Low Pressure, Corrosion Resistant Applications
Pipe Cross Materyal
Hindi Kinakalawang Na Asero Pipe Cross; ASTM A403 WP Gr. 304, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Pipe Cross: ASTM A 234 WPB, WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Mababang Temperatura Carbon Steel Pipe Cross: ASTM A420 WPL3, A420 WPL6
Alloy Steel Pipe Cross: ASTM / ASME A / SA 234 Gr. WP 1, WP 5, WP 9, WP 11, WP 12, WP 22, WP
Duplex Pipe Cross: ASTM A 815, ASME SA 815 UNS NO S31803, S32205. Werkstoff No. 1.4462
Nickel Alloy Pipe Cross: ASTM / ASME SB 336 UNS 2200 (NICKEL 200), UNS 2201 (NICKEL 201), UNS 4400 (monel 400), UNS 8020 (ALLOY 20/20 CB 3, UNS 8825 Inconel (825), UNS 6600 (Inconel 600), UNS 6601 (Inconel 601), UNS 6625 (Inconel 625), UNS 10,276 (Hastelloy C 276)
|
padron |
pag-isahin |
Walang hirap |
|
nominal na sukat |
1/2 "-48" (DN15-DN1200) |
1/2 "-20" (DN15-DN500) |
|
Wall kapal |
2 ~ 100mm |
2 ~ 50mm |
|
Bend radius |
SCH5S-SCH160, XXS |
SCH5-SCH160 |
|
uri |
krus / pagbabawas ng cross |
krus / pagbabawas ng cross |
Standards: ANSI – B 16.9
ASTM A403 – ASME SA403 – ‘Standard Specification for Wrought Austenitic Stainless Steel Piping Fittings’
ASME B16.9 – ‘ Wrought Butt welding Fittings”
ASME B16.25 – ‘Butt welding Ends’
ASME B16.28 – ‘Wrought Steel Butt welding Short Radius Elbows and Returns’
API 590-605
MSS SP-43 – ‘Fabricated & Wrought Butt-Welding Fittings for Corrosion Resistant, Low Pressure Applications’
Light Oiling, Itim Painting
Normal packing: plastic film o bubble papel nakabalot sa ibabaw ng produkto, protektahan ang mga dulo na may cap, mag-impake na may sahig na gawa sa kaso o load sa fumifation playwud pallet.
Pasadyang ginawa bilang customer kahilingan.
